品牌：SIEMENS/西门子 系列：西门子24RCE逻辑模块显示 型号：6ED1055-4MH08-0BA1+6EP3330-6SB00-0AY0 工作电压：24V
LOGO! TD text display, 6-line, 3 background colors, 2 Ethernet ports, installation accessories for LOGO! 8
| General information | |
| Product type designation |
Text display |
| Suitability for use | Can be used with LOGO! 8 and higher |
| Display | |
| Design of display | FSTN |
| Line display | |
|
● Number of lines ● Number of characters per line |
6 20 |
| Backlighting | |
| ● Type of backlighting | LED |
| Control elements | |
| Keyboard fonts | |
|
● System keys — Number of configurable system keys ● alphanumeric keyboard |
Yes 0 No |
| Installation type/mounting | |
| Wall mounting/direct mounting | No |
| Supply voltage | |
| Type of supply voltage | AC/DC |
| Rated value (DC) | 12 V; 12/24 V DC, 24 V AC |
| Power loss | |
| Power loss, typ. | 1.8 W; At 24 V DC |
| Interrupts/diagnostics/status information | |
| Diagnostics function | No |
| Degree and class of protection | |
| IP (at the front) | IP65 |
| Standards, approvals, certificates | |
| CE mark | Yes |
| UL approval | Yes |
| FM approval | Yes |
| KC approval | Yes |
| Marine approval | |
| ● American Bureau of Shipping (ABS) | Yes |
| Ambient conditions | |
| Ambient temperature during operation | |
|
● min. ● max. |
-20 °C; No condensation 55 °C |
| Ambient temperature during storage/transportation | |
|
● min. ● max. |
-40 °C 70 °C |
| Altitude during operation relating to sea level | |
| ● Ambient air temperature-barometric pressure- altitude | Tmin ... Tmax at 1 080 hPa ... 795 hPa (-1 000 m ... +2 000 m) |
| configuration / header | |
| Configuration software | |
| ● Configuration tool | LOGO! Soft Comfort V8 |
| Accessories | |
| belongs to product | LOGO! |
| Mechanics/material | |
| Design of housing | plastic |
| Dimensions | |
| Width | 128.2 mm |
| Height | 86 mm |
| Depth | 38.7 mm |
| Overall depth | 38.7 mm |
| Weights | |
| Weight, approx. | 220 g |
| Scope of supply | |
| Delivery quantity in pieces | 1 |
