Model Number: 6ES7288-1SR20-0AA0 Category: SIEMENS/PLC/S7 Product Type: PLC Module Type: Industry Automation Place of Origin: Made in Germany Warranty: 12 month warranty
| Standard specification | SIWAREX WP321 |
| Applications: | Platform scales, silo and hopper weighing, weighing in explosive areas, force measurement |
| Resolution: | up to +/- 2 million parts |
| Measuring rate: | 10 ms/100 Hz |
| Use in automation system: | • SIMATIC S7-300 |
| • SIMATIC S7-400 | |
| • SIMATIC S7-1200 | |
| • SIMATIC S7-1500 | |
| Communication interfaces: | • SIMATIC ET 200SP Bus |
| • RS485 (SIWATOOL) | |
| Rated voltage: | DC 24 V |
| Mounting: | SIMATIC ET 200SP BaseUnits Typ A0 |
| Dimensions: | 15mm width |
| Weight: | 31 g |
